Productfeatures:
Printing width of 2.5 meters, equipped with Epson i3200-U1 high-speed printheads, variable ink droplet technology.
Imported dual linear high-precision guide rail & slider + dual servo AC motor.
Higher color reproduction (four-color reduction of pure “gold/silver”); imported color management software, printhead aging complementary color function, ink saving / intelligent layout function.
Patented design of highly sensitive nozzle anti-collision system; Korea imported LED water-cooled ultraviolet curing light
Double air expansion axis + double tension floating rod before and after the release system, high-speed walking material does not go off without wrinkles, higher precision stepping
Standard with high-power static eliminator, effectively eliminate the material due to static electricity caused by flying ink, fuzzy and other issues.
Printing platform segmented independent adsorption, independent adjustment of the adsorption size function, with a strong silent turbo blower, can adapt to a variety of thick and thin materials, complexity of the material adsorption.
Technical Parameters
Print Size:2500 mm
Printhead type/number:Epson i3200-U1/ 4 pCs
Four rows of printheads Print speed:
Outer light mode: 62-123 m²/h
Inner light mode: 41-62 m²/h
Color white color: 23-28m²/h
Application Program:iSoft film/spray paint cloth, knife scraping cloth/light film/transparent static film/oil painting cloth/leather/textile, etc. (almost any soft material)
Power supply power:AC220V/ 50/60HZ/3800W
Equipment/Package Size:
L5000mm*W1400mm*H1400mm
L5090mm*W1430mm*H1450mm
Net/gross weight of equipment: 1500 kg/1800 kg
